Robotic Cutting


 for bakeries

Katana is the new standard for bakeries that want to cut their cakes and pastries with increased efficiency, creativity, cleanliness, and speed.

By combining waterjet cutting technology with robotics, we've developed a machine that can cut the most complex of shapes out of baked goods of any density, texture, and size.

Zorro

Unparalleled Creativity

Maximum Yield

Improved Speed

Interface


Interface


OUr App

Our user-friendly app allows operators to cut shapes in several different ways. They can:

  • Draw any design freehand
  • Import any 2-D image to make unique shapes like hearts or clovers, or an image as complex as a city skyline
  • Use any standard shapes like triangles, squares, circles, and spirals and maximize yield through the Tessellation Module, which intelligently nests the shapes to minimize waste
  • Cut round cakes into equal slices

Full automation


Full automation


Conveyorized

Katana is equipped with a conveyor that eliminates lost time for loading and unloading. It also integrates into automated production lines, and allows for cutting even while the product is in motion.



VISION SYSTEM

Katana is also available with a vision system that identifies the exact position and size of the incoming baked goods. Regardless of occasional upstream irregularities, Katana will give a perfect cut, every time.




3-D SCULPTING

Katana will soon feature the ability to sculpt baked goods in 3D, not just 2D profiles. Upgrade to Katana's 3D software to create spectacular baked goods and revolutionize the baking space with us.

Screen Shot 2015-02-21 at 8.27.06 PM.png

Summary


Summary


Max cut speed 3000 mm/sec
Max size of product to be cut 46cm wide x 10 cm high
Interface Built-in, touchscreen featuring our user-friendly Katana app
Modules Our app allows for cutting via grid, tessellation, round cake, or free-hand modules
Design Import outside designs in multiple formats or pull from the internal library

Harness Stainless steel high-pressure water delivery harness allows for complete freedom of movement
Product Detection Intelligent software identifies the exact position and size of incoming products
Conveyor Stainless steel wire mesh designed for robustness and ease of cleaning
Build Robust stainless steel construction that is washdown capable



QUICK SPECS

Cutting pressure Up to 4000 bar
Robot 6-axis
Power 11 kW
Interchangeable nozzle orifices
Dimensions 445 cm long x 200 cm wide x 240 cm high
Safety OSHA, CSA, and CE compliant


FAQ


FAQ


Is water retained in the product?

No, the amount of water used is negligible and the speed of the waterjet is so high that virtually no water is absorbed.

Is the water safe to use?

Our current installations all use potable water sources, ensuring that the system is 100% safe. If the water source near you is not potable, Katana can easily integrate with a water treatment system to ensure the highest safety.

How fast can it go?

Speed varies on the shape, density, and temperature of the product, but Katana can reach speeds of up to 3000 mm/sec, the fastest cutting rate on the market today.

How long does it take to switch from running one program to another?

It takes less than two minutes inside the app, including the download time to the robot.

What’s the support like for this product?

Our network of distributors undergoes extensive training to support this product worldwide.

Tech Specs


Tech Specs


QUICK SPECS

Max cut speed 3000 mm/sec
Dimensions 445 cm long x 200 cm wide x 240 cm high
Cutting pressure Up to 4000 bar
Power 11 kW
Robot 6-axis
Interchangeable nozzle orifices
Safety OSHA, CSA, and CE compliant.
Stainless steel construction
Washdown to clean

GENERAL REQUIREMENTS

Electric Supply Because Katana is shipped worldwide, we customize its electric connection to match our customers' specifications.

Compressed Air Filtered, 5.5 bar, 23 L/min consumption

Water Katana is intended for use in places where water is potable and is not subject to either microbial, bacterial, or chemical impurities.

  • A sample of the customer's water should be sent to our plant for analysis. In the event that your source is not fully compliant, we will provide you with the appropriate water treatment protocol to ensure the safe operation of the waterjet system.

Construction

  • A heavy-duty stainless steel frame, fitted with adjustable floor levelers
  • One ABB IRB-140 6-axis robot
  • Robot programming pendant for the robot with support for multiple languages
  • A highly flexible water delivery harness that provides an exceptional range of motion
  • Conveying surface made of stainless steel wire mesh.  It's the perfect substrate to facilitate water drainage and keep the product dry while providing an excellent, durable support surface
  • Conveyor is integrated on top of a water collection tank that features easy access panels for cleaning
  • One variable speed SEW Eurodrive conveyor motor

Interface

  • A state of the art, user-friendly interface allows operators to cut shapes in several different ways.
    • Draw any design freehand
    • Import any 2-D image to make unique shapes like hearts or clovers, or an image as complex as a city skyline
    • Use any standard shapes like triangles, squares, circles, and spirals and maximize yield through the Tessellation Module, which intelligently nests the shapes to minimize waste
    • Cut round cakes into equal slices
  • Industrial Siemens touchscreen
  • Intelligent software identifies the exact position and size of incoming products

Electric

  • NEMA 4x compliant controls cabinet (including NEMA 4-rated air cooling fans) that houses both the robot controls and system controls
  • Compliant with UL and CE standards
  • Available with either Allan Bradley or Siemens components
  • Designed to meet user-specified voltage

Safety

  • Features heavy-duty transparent polymer guard doors fitted with a safety interlock
  • OSHA, CSA, and CE compliant guarding
  • 5 integrated E-stop buttons
  • Robot is equipped with collision detection to maximize safety
  • Built-in water filtration to ensure the nozzle is not damaged by particulates

Speed

  • Max speed of 3000 mm/sec (for straight lines)
  • Average speeds of between 50-500 mm/sec for higher-density/frozen products
  • Interchangeable nozzle orifices allow for fine-tuning based on density, temperature, and other variables.
